Product Side Filtering

This is a new feature added into our latest version. Product Side Filtering allow your customers to filter or narrow the list of products at product listing page, by price range (just switch the price scroll bar), or enter the wanted keyword and also to narrow them by product features e.g. colors.

To configure this Product Side Filtering, merchant can login to administration : Modules > Side Filter Manager

There will be two tabs you can configure (View/Edit) and (Configuration):

To change the configuration settings for Side Filter, click Configuration tab.

xproductfiltering_sidefilter_enable	Setting this to Yes to enable side filter on product listings page.
xproductfiltering_page	Side Filter Manager URL. Default page is shopa_editdisplayfilter.asp
xproductfiltering_sidefilter_position	Side filter to be placed either left or right on the site. Enter left to show side filter in left column. Enter right to show side filter in right column.
xproductfiltering_componenttype	List of form field type of side filter. Default list are : textbox,pricerange,dropdown,radiobox,checkbox. You probably no need to change this config value.
xproductfiltering_pricerange_min	Minimum price on side filter price range. Take example, if you want to display a price range filter for your customers from $0 to $10,000. Then you should enter 0 for this config.
xproductfiltering_pricerange_max	Maximum price on side filter price range. Take example, if you want to display a price range filter for your customers from $0 to $10,000. Then you should enter 10000 for this config.
xproductfiltering_seemore_limit	This is only used if you have setup side filter for a product feature. If product features checkbox or radiobox type has more than this amount, it will display a button "See more". Default is 3. For example, you setup a side filter for product feature Colors, this is how the side filter looks : Now, let’s say you change this config value to 2. This is how the side filter looks :

Merchant can add how many sections to show in the Side Filter. Click the “View/Edit” tab.

By default, there is will be three existing sample records for Side Filter.

To add a new filter section to be displayed in the Side Filter, click “Add a Record”.

Then enter each fields with value that suits your liking.
Take example, we want to add a new filter for product features shirt size, and you want this filter section only apply for certain category eg. Shirt category.

Filter Caption : Enter the title of the filter section e.g. Size
Filter Type : Select form fields type you want for this filter e.g. Checkbox
Product Features To Be Retrieved : Select a product feature from the list. VPCart will automatically list all of your site products features records here. Let’s say we pick “Size”.
Show on Search : Set Yes to apply on search result page. Set No if not to apply on search result page.
Hide : Set Yes if you do not use this filter section and it will be hidden. Set No to display it.
Sort Order in Number : Enter the sequence number for your current filter section. E.g. 04

Categories : Tick any of the categories from checkboxes that you want this new filter section to show. Eg. Shirt.

This means, only products from Shirts category will be able to view this new “Size” filter section.

This is the preview of the new “Size” filter when we browse to Shirt category product listing.
